Mimsafe Variocage Crash Tested Crates

** Images and sizing below - for more images visit our Facebook page **

SAFETY OVER ANYTHING!

We are official Mimsafe & Variocage  Distributors.

We keep stock of every size crate in store which includes single crates, double crates, hatchback crates and minimax crates.

!!! BOOK FIRST !!! - Our fitting service provides you with the chance to see you preferred crate assembled and in your car with your dog so that you know a) it fits in the vehicle and b) it is a suitable size for your dog. If you wish to view a crate please contact us to make an appointment as we may have to assemble the crate(s) that you wish to view.

Contact Darren on 01215509095 and leave details of what car you have, the year of car you have and also what dog(s) the crate is for with a general weight guide.

We can now send flat pack crates out to customers direct we ask that you speak to us before hand for advice on sizing - please ring store to arrange.

for a rough guide of sizing for your dog visit the mimsafe model selector - please note that it is always advisable to check for sizing with us here in store as the model selector does not explain what length the crates are to made up to.

Concept

For more than twenty years, Mim Construction AB (the manufacturers of the crate, based in Sweden) has worked with functional designs of safety details in the vehicle industry. They have documentation from hundreds of crash-tests, where their protection details are used. Mim has followed the major car-manufacturers´ use of crumple-zones.

The Variocage was developed based on their long experience in the production of safety accessories. The initial models were sold by the thousands and the recent models are today exported to many European countries.

Escape door
If the front gates are blocked the escape door can be used. In a few simple operations the rear section can be removed (undoing two bolts on the single crates; three bolts on the doubles).

Crumple zone
In a rear-end collision the cage will be compressed in a controlled manner to the same extent as the crumple zones of the car. This means that the rear seat back will not be pushed forward by the cage, minimizing the risk of damage to both passengers and dog.

Double crate with detachable divider
The mid-section easily adjusts sideways if one of the dogs needs more space. If you have a large dog or if you want to give a single dog more space, the mid-section is easily detached. The cage can easily be “tailor-made” for the car by adjusting the length to suit the size of your boot space.


Crash Test Report

MIM Construction AB has evaluated the dog crate Variocage in car crashes from the safety aspect of both the dog and passengers. Out of a variety of crashes the rear-end collision is probably the biggest threat to passenger safety. The luggage compartment is a part of the deformation zone around the passenger compartment that protects passengers from intrusion in collisions. In a rear-end collision the rear-end is pushed forward by the intrusion caused by the hitting vehicle. Objects in the luggage compartment are then pushed forward. The amount of intrusion is limited by the stiffness of the car and the speed and energy of the hitting vehicle. A dog crate placed in the luggage compartment affects the balance of the system. If the crate is too stiff the back of the rear seats will yield and collapse in a rear-end crash.

When passengers occupy the rear seat the change of the deformation zone becomes dangerous if the back of the rear seat does not stop the dog crate. This type of collision is common in all countries. It is thus essential that the crate is constructed in a way that makes it collapse in a controlled way in severe rear-end crashes.

The speed that was used in the rear-end crash test was 30 km/h. It is equal to at a stand still getting hit from behind by a car with the same weight as the hit car doing 55 km/h. Part of a Volvo V70 body was placed on a crash test sled. The crate was then placed in the luggage compartment against the seat back. Two 35-kg dog dummies were placed inside the crate. The crate was pushed forward during the crash by a plate big enough to hit the entire rear-end of the crate. The plate was used to simulate the intrusion of the hitting vehicle.

A Variocage XL dog crate for two dogs was tested. The loading of the seat back was moderate and no visible deformation of the seat structure could be found after the test.

A frontal collision test was also performed. Two 35-kg dummies were placed in a Variocage XL for two dogs. The test speed was 50 km/h and the retardation was approximately 24 g, which corresponds to 2,5 tonnes of loading of the rear seat. The crate was slightly compressed by its own weight during the collision. No sharp edges were found. Both gates could be opened. The emergency gate was not jammed and could be opened. The front wall of the crate was deformed by the dummies during the crash test. That was positive as it took care of some of the energy during impact and it would have helped the dogs in a real crash. No deformation of the seats could be found.

The forces in a roll over are difficult to create in a controlled way in a crash lab. They are randomised and can come from any direction. The falling distance in a roll over is not very high and the crate is close to the centre of gravity. It is thus the impact from the falling that is interesting and easy to create. A Variocage XL single crate was tested in a drop test to see if the crate could handle forces in the corner of the gate. The crate was dropped from a height of 70 cm, which corresponds, to a speed change of 13,3 km/h when it hits the concrete floor. With the lower hinge corner of the crate facing down and a 45-kg dummy inside the impact of the crate is quite rough. The crate handled the impact well and did not open or crack in any other way that would be dangerous to the dog.

Mimsafe Variocage Crash Tested Crates - Sizes and prices

Varicage Model
Price
Length
(Telescopic min & max)
Width
Height
Weight
Description
Hatchback Single Large 00367
£495
600mm - 820mm
23.5" - 32"
555mm
22"
650mm
25.5"
12kg
Suitable for most hatchback cars with a sill
Hatchback Single XL 00368
£525
600mm - 820mm         23.5" - 32"
700mm
27.5"
650mm
18"
13kg
suitable for most hatchback cars with a sill
Single Minimax Large 00390
£400
570mm - 770mm
22.5" - 30"
450mm
17.5"

455mm
18"
10kg
small crate designed for small breed dogs (small gaps between bars)
Single Minimax XL 00366
£420
570mm - 770mm
22.5" - 30"
555mm
22"
455mm
18"
13kg
small crate designed for small breed dogs (small gaps between bars)
Single XS  00376
£400
730mm - 990mm
28.5" - 39"
555mm
22"
590mm
23"
16kg
Standard single crate
Single Large 00363
£420
760mm - 1030mm
30" - 40.5"
555mm
22"
650mm
25.5"
17kg
best seller for single medium-large dogs
Single Large + (SXL but lower) 00379
£470
810mm - 1030mm
31.5" - 40.5"
700mm
27.5"
690mm
27"
22kg
new size
Single XL 00380
£470
810mm - 1030mm
31.5" - 40.5"
700mm
27.5"
715mm
28"

22kg
best seller for single large to XL dogs
Single XXL 00378
£570
820mm - 1060mm
32" - 41"
700mm
27.5"
780mm
31.5"
26kg
new size
Double Small 00377
£595
730mm - 990mm
28.5" - 39.5"
930mm
36.5"
590mm
23"
29kg
2 door crate with removable divider
Double Medium 00383
£620
760mm - 1030mm
30" - 40.5"
930mm
36.5"
650mm
25.5"
32kg
2 door crate with removable divider
Double Large 00361
£635
760mm - 1030mm
30" - 40.5"
990mm
39"
650mm
25.5"
35kg
2 door crate with removable divider
Double Large + (DXL but lower) 00362
£665
810mm - 1030mm
31.5" - 40.5"
990mm
39"
690 mm
27"
36kg
2 door crate with removable divider
Double XL 00364
£665
810mm - 1030mm
31.5" - 40.5"
990mm
39"
715mm
28"
36kg
2 door crate with removable divider
Double XXL 00365
£700
810mm - 1030mm
31.5" - 40.5"
1060mm
41.5"
715mm
28"
37.5kg
2 door crate with removable divider
Double XXL+ 00382
£805
820-1060mm
32" - 41.5"
1060mm
41.5"
780mm
31.5"
39kg
new size
very large 2 door crate with removable divider
Double Maximum
£990
920mm - 1160mm
36" - 45.5"

1060mm
41.5"

845mm
33"

51kg
please check stock as this crate is too big for most vehicles
French Bulldog in a Minimax

French Bulldog in a Minimax Crate

Poodle & Cavalier King Charles in a Single XL

Poodle & Cavalier King Charles in a Single XL

Single XL in a Land Rover Discovery

Single XL in a Land Rover Discovery (for a Rottweiler)

Malamute variocage

Malamute in Half a Double Extra Large (Divider Fitted)

D Lge 31'' 2 small Labs Destiny  Ella 3

2 Labradors in a Double Large

Single Large Variocage

Large Cocker Spaniel in a Single Large sitting up

findus
Single Variocgage

Available in Extra Small, Large & Extra Large

Variocage Double

Double Crates Are Available in DBL Small, DBL Medium, DBL Large, DBL L+, DBL XL, DBL XXL+ ,DBL XXL+ & DBL Maximum. They come with a removal divider.

Minimax Variocage

Available in Large & Extra Large, suitable in a car where bigger crates are too big for a smaller breed dog.

Variocage Compact Hatchback

Available in Large & Extra Large. The crate has a lip at the front to fit into hatchback cars.
